While floating through the molten tin, the combination of gravity and surface tension results in smooth and flat surfaces on both sides.
a) Smooth and flat surface and good vision.
b) Excellent optical performance.
c) Stable chemical properties.
d) Resistant to acid, alkaline, and corrosion.
Specification of Float Window
|
Material
|
Float Glass
|
|
Diameter
|
1 to 500 mm
|
|
Diameter Tolerance
|
+0/-0.02 mm
|
|
Thickness Tolerance
|
±0.01 mm
|
|
Surface Quality
|
10-5
|
|
Surface Figure
|
λ/10
|
|
Parallelism
|
1 Minute
|
|
Coating
|
Uncoated, AR, HR, Beamsplitter, etc.
|
